Mechanical (Mass and Mass Related)
This calibration list covers our scope of activities for Mechanical (Mass and Mass Related) measuring instruments. If you wish to calibrate an equipment which is not listed here or the range exceeds the stated value, please do not hesitate to contact us for further enquiries.
Download
| Item Description | Range | Onsite | Country |
|---|---|---|---|
| Scales and Balances | Up to 3000 mm | YES | Bangkok, Thailand |
| Torque Wrenches | Up to 2000 N·m | YES | Bangkok, Thailand |
| Torque Meter / Gauge | 2 N·m Up to 1000 N·m | YES | Bangkok, Thailand |
| Force Testing Machines1 and Load Cells Compression and Tension | 0 to 500 kN. | YES | Bangkok, Thailand |
| Force Gauges | 0 N to 5000 N | NO | Bangkok, Thailand |
| Universal Length Measuring Machines (ULM) 1 Force | 0 N to 5 N | YES | Bangkok, Thailand |
| Rockwell Hardness Testers | Force: (15 to 150) kgf Indenter Angle: 120° Indenter Radius: 0.2 mm Indenter Ball Diameter: 1.5875 mm, 3.175 mm Hardness: (10 to 100) HRBW, (20 to 95) HRA, (10 to 70) HRC, (70 to 94) HR15N, (67 to 93) HR15T, (42 to 86) HR30N, (29 to 82) HR30T, (20 to 77) HR45N, (10 to 72) HR45T |
YES | Bangkok, Thailand |
| Brinell Hardness Testers | (100 to 600) HBW | YES | Bangkok, Thailand |
| Vickers Hardness Testers | Force(100 to 50000) gf Indenter Angle(136, 148.11)° Indenter Length(0 to 1000) µm Hardness(100 to 1000) HV |
YES | Bangkok, Thailand |
| Hardness Test Block Rockwell | (20 to 95) HRA (10 to 100) HRB (10 to 70) HRC Up to 100 HR15N Up to 100 HR15T Up to 100 HR30N Up to 100 HR30T Up to 100 HR45N Up to 100 HR45T | YES | Bangkok, Thailand |
| Durometer Force (expressed as degrees or percentage of scale pointer rotation) | (0 to 100) % | NO | Bangkok, Thailand |
| Pressure/ Vacuum Gauges/ Standard Pressure Gauge/Digital Test Gauge | (-1 to 0) bar (0 to 0.7) bar (0.7 to 70) bar |
YES | Bangkok, Thailand |
| Pressure/ Vacuum Gauges/ Standard Pressure Gauge/Digital Test Gauge | (70 to 700) bar (700 to 1500) bar (10 to 1000) bar |
YES | Bangkok, Thailand |
| Mass Artifacts | 1 mg – 1 g | NO | Bangkok, Thailand |
| Mass Artifacts | Mass Artifacts: 2 g, 5 g - 10 kg | NO | Bangkok, Thailand |
| Mass Artifacts | 20 kg - 50 kg | NO | Bangkok, Thailand |
| Mass Flow Rate | Flow Rate: 0.5 mg/min – 592 g/min | YES | Bangkok, Thailand |
| Volumetric Flow Rate Gas | Flow Rate: 0.01 – 500 SCCM, 0.5 – 500 LPM | YES | Bangkok, Thailand |
| Burette | 1 ml – 100 ml | NO | Bangkok, Thailand |
| Graduated Pipette | 0.1 ml – 25 ml | NO | Bangkok, Thailand |
| Measuring Cylinder | 1 ml – 2000 ml | NO | Bangkok, Thailand |
| Volumetric Flask | 1 ml – 2000 ml | NO | Bangkok, Thailand |
| Volumetric Pipette | 1 ml – 100 ml | NO | Bangkok, Thailand |
| Micropipette | 10 ul – 10000 µl | NO | Bangkok, Thailand |
| Syringes | 10 ul – 10000 µl | NO | Bangkok, Thailand |
| Beaker / Erlenmeyer | 10 ml – 2000 ml | NO | Bangkok, Thailand |
| Dispenser | 1 ml - 200 ml | NO | Bangkok, Thailand |
| Viscosity Cup / Dip-type Viscosity cup | (0 to 250) sec | NO | Bangkok, Thailand |
| Rotational Viscometer | 5 mPa·s – 100000 mPa·s | NO | Bangkok, Thailand |
| Scales and Balances | 0 g – 400 Kg | YES | Singapore |
| Torque Tools | 0 N·m to 1000 N·m | YES | Singapore |
| Torque Meter/Gauge | (0 to 150) kgf·cm | NO | Singapore |
| Durometers (Force only) Types A, B, E & O Types C, D, & DO | (0 to 100) | YES | Singapore |
| Rockwell Hardness Testers | (10 to 100) HRBW (20 to 95) HRA (10 to 70) HRC |
YES | Singapore |
| Vickers Hardness Testers | 100 to 1000 HV | YES | Singapore |
| Brinell Hardness Testers | 100 to 600 HBW | YES | Singapore |
| Pressure Gauges | -0.9 to 2,700 Bar | YES | Singapore |
| Air Flow Meters | Up to 500 SCCM, Up to 50 LPM, Up to 500 LPM | YES | Singapore |
